触控面板控制器
HiTouch™
奇景提供用于中小尺寸电容式触控显示屏的触控芯片解决方案，应用范围包括智能型手机、平板电脑与各种行动装置等。
技术优势
- True multi-point (10-Finger) single chip touch panel controller
- Strong Anti-noise Capability
- LCM noise immunity – support sensor with full lamination w/o shielding layer
- AC noise immunity – pass most AC chargers with various noise conditions
- Better User Experience Enabled by HiTouch™
- Real, full-auto calibration without SW interference
- Various Sensor Structure Supported
- Support AMOLED on-cell and typical out cell panel
手机与穿戴装置应用
| Part No. | Channel Number | Panel type | Package | Fingers | Report Rate | Interface | Active Stylus |
|---|---|---|---|---|---|---|---|
| HX8527-E44 | 44 | LCD out-cell | QFN56 6*6 | 10 | 120Hz | I2C | NA |
平板电脑与笔记本电脑应用
| Part No. | Channel Number | Panel type | Package | Fingers | Report Rate | Interface | Active Stylus |
|---|---|---|---|---|---|---|---|
| HX85200-A118-R | 118ch | Rigid AMOLD On-cell | BGA154 9.9×5 | 10 | 240Hz@5p,180Hz@10p | I2C/SPI | Support |
| HX85200-A118-F | 118ch | Flexible AMOLD On-cell | BGA154 9.9×5 | 10 | 180Hz@10p | I2C/SPI | Support |
| HX85200-A138-R | 138ch | Rigid AMOLD On-cell | BGA216 12.7×6.4 | 10 | 240Hz@5p,180Hz@10p | I2C/SPI | Support |
| HX85200-A138-F | 138ch | Flexible AMOLD On-cell | BGA216 12.7×6.4 | 10 | 180Hz@10p | I2C/SPI | Support |
Automotive Applications
| Part No. | Channel Number | Panel type | Package | Fingers | Report Rate | Interface | Cascade Function |
|---|---|---|---|---|---|---|---|
| HX8530-L97-F | 97ch | Flexible/Rigid AMOLED On-cell | LQFP128 14×14 | 10 | 180Hz@10p | I2C/SPI | _ |
| HX8530-L118-R | 118ch | Rigid AMOLD On-cell | LQFP176 20×20 | 10 | 180Hz@10p | I2C/SPI | _ |
| HX8530-L118-F | 118ch | Flexible/Rigid AMOLED On-cell | LQFP176 20×20 | 10 | 180Hz@10p | I2C/SPI | _ |
| HX8530-L138-F | 138ch | Flexible/Rigid AMOLED On-cell | LQFP216 24×24 | 10 | 180Hz@10p | I2C/SPI | _ |
| HX8530-LC138-F | 138ch | Flexible/Rigid AMOLED On-cell | LQFP216 24×24 | 10 | 120Hz@10p | I2C/SPI | Support |
