HM8030 QUXGA VividSense™

15fps 1/3.2″ 8.1MP RGB Color CIS Low Profile 1.4μ Pixel Technology

The HM8030 is an advanced 8 Megapixel CMOS Image Sensor (CIS) designed for next generation Smartphone, Tablet, and other high-resolution camera accessories.

The HM8030 utilizes an advanced 1.4µ ultralow profile pixel process technology that delivers excellent crosstalk performance to enable rich color reproduction under a broad range of lighting conditions. The sensor operates at 15 frames per second in QUXGA (3280 x 2464) resolution with support for 2 x 2 binning up to 30 frames per second, while preserving native field of view.

The HM8030 supports a dual lane MIPI-CSI2 serial interface that transfers 10 bit RGGB RAW data format up to 662Mbps per lane. All sensor parameters are controlled through a simple 2-wire serial camera interface.

影象传感器特色

• 8MP (3296 x 2480 with 16 border pixels) CMOS Image Sensor for 1/3.2” optical format camera module
• Advanced 1.4µ pixel delivers excellent crosstalk, uniformity, and noise performance
• 15 frames per second full frame readout with support for 30 frame per second 2 x 2 binning
• Global analog gain up to 16x (24.1dB)
• Programmable Region of Interest provides flexible pixel array readout
• Integrated LDO simplifies camera design utilizing only two power supplies of 2.8V and 1.8V
• Integrated OTP for module tracking and calibration information
• 2-lane MIPI CSI2 supports RAW10 data format
• Simple 2-wire serial interface for register programming
• Available in Bare Die (RW) for ≤8.5mm2 COB module
